Rated Voltage: 10kV / 12kV Max
Application: Indoor MV Switchgear (FN5 compatible), Ring Main Units, Electrical Panels
The FUYI ZJ-10Q series are high-quality epoxy resin indoor post insulators designed for 10kV switchgear and electrical installations. Available in two standard heights 130mm with 75mm diameter, these insulators provide reliable electrical insulation and mechanical support for live conductors.
| Parameter | ZJ-10Q Ø75×130 |
|---|---|
| Height | 130 mm |
| Diameter | 75 mm |
| Top Thread | M10 / M12 |
| Base Thread | M16 |
Quality Assruance
FUYI ZJ-10Q insulators are produced using Automatic Pressure Gelation (APG) technology with vacuum mixing, ensuring void-free internal structure and consistent quality.
Customization Options
Custom dimensions, thread sizes, and colors are available —Just contact us with your requirements. For technical inquiries, please provide your rated voltage and installation type.
