Rated Voltage: 35kV
Application: PT Truck (Voltage Transformer Truck), Isolating Truck, Withdrawable Switchgear
IEC Standard Compliance:IEC 60060-1/ IEC 60270
The FUYI 35kV interconnected insulator is specially designed for PT trucks and isolating trucks in high voltage withdrawable switchgear applications. Manufactured from high-quality epoxy resin with precision-engineered embedded contacts, this insulator provides reliable electrical insulation and mechanical support for moving contacts in 35kV switchgear systems.
High-quality epoxy resin construction with embedded contacts
Designed specifically for 35kV PT and isolating truck applications
Suitable for various current ratings
Precision-engineered for perfect fit in standard switchgear
Threaded inserts for secure mounting
Optimized for high voltage applications
Technical Specification
| Parameter | Value |
|---|---|
| Rated Voltage | 35kV |
| Power Frequency Withstand Voltage | 95kV (1 min) |
| Lightning Impulse Withstand Voltage | 200kV (peak) |
| Partial Discharge | ≤5pC at 35kV |
Quality Assruance
FUYI 35kV interconnected insulators are produced using advanced epoxy resin casting technology with precision contact embedding, ensuring void-free internal structure and optimal electrical performance for high voltage applications.
