Rated Voltage: 12kV
Rated Current: 1600A ~ 3150A
Application: PT Truck (Voltage Transformer Truck), Isolating Truck, Withdrawable Switchgear
The FUYI 12kV high-current interconnected insulator is specially designed for PT trucks and isolating trucks in medium voltage withdrawable switchgear requiring 1600A to 3150A current ratings. Manufactured from high-quality epoxy resin with enhanced conductive components, this insulator provides reliable electrical insulation and mechanical support for high-current applications in 12kV switchgear.
High-quality epoxy resin construction with enhanced embedded contacts
Designed for high-current applications (1600A~3150A)
Optimized contact design for reduced temperature rise
Technical Specification
| Parameter | Value |
|---|---|
| Rated Voltage | 12kV |
| Rated Current | 1600A ~ 3150A |
| Power Frequency Withstand Voltage | 42kV (1 min) |
| Lightning Impulse Withstand Voltage | 75kV (peak) |
Quality Assruance
FUYI high-current interconnected insulators are produced using advanced epoxy resin casting technology with precision-engineered contact embedding, ensuring void-free internal structure and optimal electrical performance.
