Rated Voltage: 24kV
Rated Current: 2000A – 2500A
Application: Medium Voltage Switchgear (Withdrawable Type), 24kV High-Current Electrical Connection Systems
The contact box is a key component for 24kV medium voltage switchgear, enabling reliable power transmission in high-current distribution systems.
The epoxy resin body provides excellent insulation, mechanical strength, and sealing against dust and moisture for long-term reliability in 24kV high-current applications. Terminals are made of high-conductivity copper with enhanced tin or silver plating for stable performance under high current loads. Contacts are precision-engineered from high-strength copper alloy with an optimized high-current design, offering superior conductivity, wear resistance, and high temperature tolerance.
| Model | CH3-24kV/250 |
|---|---|
| Rated Voltage | 24kV |
| Rated Current | 2000A – 2500A |
| Installation Method | For Medium Voltage Withdrawable Switchgear |
| Wiring Method | Crimping type |
| Insulation Material | Epoxy resin |
| Number of Connectors | As per standard configuration |
| Application | Indoor use |
