Rated Voltage: 12kV
Rated Current: 1600A – 2000A
Application: Medium Voltage Switchgear (Withdrawable Type), Electrical Connection Systems
The contact box is a key component in medium voltage switchgear, enabling reliable power transmission between busbars and equipment.
The epoxy resin body provides excellent insulation, mechanical strength, and protection against dust and moisture.
| Model | CH3-10Q/208 |
|---|---|
| Rated Voltage | 12kV (max) |
| Rated Current | 1600A – 2000A |
| Installation Method | For Medium Voltage Withdrawable Switchgear |
| Wiring Method | Crimping type |
| Insulation Material | Epoxy resin |
| Number of Connectors | As per standard configuration |
| Application | Indoor use |
